KX Press Plate Dies for Heavy Duty Table Press Only

  • These pressing plates can be used with shape cutters or logo embossing dies.

    • Top and bottom plates do *not* completely press together when press handle is compressed:
      • If using our current DK93 table press, there is a 7mm gap (approx 5/16")
      • If using the older model DK98 table press, there is a 3mm gap (approx 1/8").
    • Clearance between top and bottom plates is 30mm (approx 1 1/8").
    • Diameter is 75mm (just under 3").
    • Plate thickness is 8mm (approx 5/16").
    • Plates are heavy -- over 1 lb. Please handle with care.
    • Tip: Placing a piece of cutting mat on the lower die may help to get cleaner cuts.

    REQUIRED TOOLS:  These press plates will only fit KAM heavy duty table presses with adapters -- also see last thumbnail image: ( which tool do I have?)
  • Bottom die shank: approx 9.9mm diameter (slightly larger than 3/8")
    Top die shank:  approx 8mm (5/16") diameter (screws in - M8 threading)

  • Dies are industrial equipment and may have scratches, rust, oil or other cosmetic imperfections that will not hinder their function. Remove any remaining oil on dies by attaching several snaps to scrap fabric. Returns or exchanges cannot be accepted unless a defect affects function.
